No Carrier Tape

Molecule Gradient Tape 200A / 300A Series

High Adhesion / Good Followability

Feature

Molecule gradient tape is a tape with adhesive strength 1.5 to 2 times compared to conventional double sided tape.

By applying gradation to the molecular weight with the
same kind of resin from the center to the outside, it
increases the interlayer strength and creates a very
strong bonding force.

The outer adhesive layer has selected a special low
molecular weight adhesive layer that adheres well to
adherends (dissimilar materials).

Click Here for Details



Product Name	Thickness [mm]	Structure	Adhesive Strength [N/25mm] SUS	Application	Notes	Technical Data
200A5	0.005	Low Molecular Polymer Low Molecular	5.0	Fixing of nameplate, insulator, difficult adhesion member(polymer PE etc)	BTO Double Separator
200A10	0.01	Low Molecular Polymer Low Molecular	8.0	Fixing of nameplate, insulator, difficult adhesion member(polymer PE etc)	BTO Double Separator
200A20	0.02	Low Molecular Polymer Low Molecular	9.0	Fixing of nameplate, insulator, difficult adhesion member(polymer PE etc)	BTO Double Separator
200A30	0.03	Low Molecular Polymer Low Molecular	10.0	Fixing of nameplate, insulator, difficult adhesion member(polymer PE etc)	-
200A50	0.05	Low Molecular Polymer Low Molecular	18.0	Fixing of nameplate, insulator, difficult adhesion member(polymer PE etc)	-
300A80	0.08	Low Molecular Polymer Low Molecular	20.0	Fixing of nameplate, insulator, difficult adhesion member(polymer PE etc)	BTO
300A100	0.1	Low Molecular Polymer Low Molecular	22.0	Fixing of nameplate, insulator, difficult adhesion member(polymer PE etc)	-
200A30B	0.03	Black Low Molecular Black Polymer Black Low Molecular	9.0	Black double sided tape with molecular gradient function Shading of smartphone, camera and LCD	BTO
200A50B	0.05	Black Low Molecular Black Polymer Black Low Molecular	15.0	Black double sided tape with molecular gradient function Shading of smartphone, camera and LCD	BTO

Waterproof / Chemical Resistance Molecular Gradient Tape 300Z Series

High Adhesion / Waterproofness / Chemical Resistance

Feature

Molecular gradient tape is an epoch-making double sided tape which changed the concept of conventional by gradation of molecule.

Since the foam substrate is not used, there is no concern of flooding due to bubbles and it is excellent in waterproofness.

This double sided tape is not limited to metals but has high adhesion to glass and resins.

Click Here for Details



Product Name	Thickness [mm]	Structure	Adhesive Strength [N/25mm] SUS	Application	Notes	Technical Data
300Z150B/W	0.15	Low Molecular Polymer Low Molecular	32.0	Fixing and waterproofing of smartphone and tablet etc.	BTO B is black W is white
300Z200B/W	0.2	Low Molecular Polymer Low Molecular	36.0	Fixing and waterproofing of smartphone and tablet etc.	BTO B is black W is white
300Z250B/W	0.25	Low Molecular Polymer Low Molecular	39.0	Fixing and waterproofing of smartphone and tablet etc.	BTO B is black W is white
300Z300B/W	0.3	Low Molecular Polymer Low Molecular	44.0	Fixing and waterproofing of smartphone and tablet etc.	BTO B is black W is white
300Z400B/W	0.4	Low Molecular Polymer Low Molecular	45.0	Fixing and waterproofing parts such as cars and houses.	BTO B is black W is white
300Z500B/W	0.5	Low Molecular Polymer Low Molecular	46.0	Fixing and waterproofing parts such as cars and houses.	BTO B is black W is white
300Z600B/W	0.6	Low Molecular Polymer Low Molecular	46.0	Fixing and waterproofing parts such as cars and houses.	BTO B is black W is white
300Z800B/W	0.8	Low Molecular Polymer Low Molecular	46.0	Fixing and waterproofing parts such as cars and houses.	BTO B is black W is white
300Z1000B/W	1.0	Low Molecular Polymer Low Molecular	46.0	Fixing and waterproofing parts such as cars and houses.	BTO B is black W is white
300Z1200B	1.2	Low Molecular Polymer Low Molecular	46.0	Fixing and waterproofing parts such as cars and houses.	BTO B is black

Heat Resistant Molecule Gradient Tape 200Y Series

High Heat Resistance

Feature

Molecular gradient tape is an epoch-making double sided tape which changed the concept of conventional by gradation of molecule.
　
This double-sided tape can withstand high temperature environments up to 300℃ and can be laminated at room temperature.

Click Here for Details



Product Name	Thickness [mm]	Structure	Adhesive Strength [N/25mm] SUS	Application	Notes	Technical Data
200Y12.5	0.0125	Heat Resistant Low Molecular HeatResistant Polymer HeatResistant Low Molecular	7 (11.5)	Laminating with heat-resistant members and heat-resistant films	BTO *() is data after heating lamination
200Y30	0.03	Heat resistant low molecular weight Heat resistant polymer Heat resistant low molecular weight	8.5 (15.0)	Laminating with heat-resistant members and heat-resistant films	BTO *() is data after heating lamination
200Y50	0.05	Heat resistant low molecular weight Heat resistant polymer Heat resistant low molecular weight	10 (22.0)	Laminating with heat-resistant members and heat-resistant films	BTO *() is data after heating lamination

Molecule Gradient Tape for Fixing Interior Parts 954 Series

High Adhesion / Good Followability / High Heat Resistance

Feature

・954 series is a strong adhesive tape which is very sperior in initial tack.
・It's available to fix some parts on hardly adhesive adherend made of PE, PP etc
and UV coating subsutrate.
・Suppresses the repulsion of foams, etc., with excellent curved surface followability.
・We produce our products in consideration of the VOC 13 substances
designated by the guidelines of the Ministry of Health, Labor and Welfare.



Product Name	Thickness [mm]	Structure	Adhesive Strength [N/25mm] SUS	Application	Notes	Technical Data
954-3	0.03	Low Molecular Polymer Low Molecular	9.0	For bonding automotive interior parts such as cars	BTO
954-5	0.05	Low Molecular Polymer Low Molecular	17.0	For bonding automotive interior parts such as cars	BTO
954-8	0.08	Low Molecular Polymer Low Molecular	19.0	For bonding automotive interior parts such as cars	BTO
954-10	0.1	Low Molecular Polymer Low Molecular	21.0	For bonding automotive interior parts such as cars	BTO

Silicone / Acrylic Molecule Gradient Tape 300ZUV Series

High Adhesion / Waterproof / Differential

Feature

Molecular gradient tape is an epoch-making double sided tape which changed the concept of conventional by gradation of molecule.
　
One side silicone adhesive and one side acrylic adhesive differential specification. It can be adhered to various adherends including difficult-to-adhere materials such as silicone.



Product Name	Thickness [mm]	Structure	Adhesive Strength [N/25mm] SUS	Application	Notes	Technical Data
300Z250UV	0.25	Silicone Polymer Acrylic	Sillcone Side : 15 Acrylic Side : 35	Bonding to difficult-to-bond materials such as silicone rubber	BTO
300Z300UV	0.3	Silicone Polymer Acrylic	Sillcone Side : 18 Acrylic Side : 40	Bonding to difficult-to-bond materials such as silicone rubber	BTO

May Clean Gel

Shock absorption / Good adhesion

Feature

This product is an acrylic gel tape excellent in shock absorption, damping and waterproofing.



Product Name	Thickness [mm]	Structure	Adhesive Strength [N/25mm] SUS	Application	Notes	Technical Data
MGCS50	0.5	Separator Gel tape Separator	35	Fixing and cushioning of LCD, touch sensor, battery etc.	BTO
MGCS100	1.0	Separator Gel tape Separator	45	Fixing and cushioning of LCD, touch sensor, battery etc.	BTO
MGCS150	1.5	Separator Gel tape Separator	52	Fixing and cushioning of LCD, touch sensor, battery etc.	BTO

Renesas Gel

Double sided adhesive gel tape for rework

Feature

It is a double-sided adhesive gel tape which can be repaired. Even after sticking with original technology, it clears cleanly.

It is easy to repair by stretching with its tip and it can be used for various purposes.



Product Name	Thickness [mm]	Structure	Adhesive Strength [N/25mm] SUS	Application	Notes	Technical Data
RSG15	0.15	Separator Gel tape Separator	19.0	Temporary fixing and repair of posters, parts and members	BTO
