Optical Clear Adhesive
May Clean Gel "MGSF / CS" Series
High Transparency / High Adhesion
Feature
This product is extremely high transparency and adhesive gel sheet based on acrylic resin called organic glass.
This product is optically excellent double sided tape such as strong adhesion, shock absorption, reliability and prevention of corrosion of metal film of touch sensor.
This product is optically excellent double sided tape such as strong adhesion, shock absorption, reliability and prevention of corrosion of metal film of touch sensor.
Application
Applications for pasting optical members such as LCD, OLED, touch sensor
It also contributes to improvement of the visibility of the display by filling the air gap between the optical members
It also contributes to improvement of the visibility of the display by filling the air gap between the optical members
Product Name |
Thickness |
Structure |
Adhesive Strength |
Tt |
Notes |
Technical Data |
MGSF2.5 |
0.025 |
Separator Acrylic Gel Separator |
11.0 |
99 |
BTO |
 |
MGSF5 |
0.05 |
Separator Acrylic Gel Separator |
13.0 |
99 |
BTO |
|
MGSF7.5 |
0.075 |
Separator Acrylic Gel Separator |
15.0 |
99 |
BTO |
|
MGSF10 |
0.1 |
Separator Acrylic Gel Separator |
20.0 |
99 |
BTO |
|
MGSF12.5 |
0.125 |
Separator Acrylic Gel Separator |
21.0 |
99 |
BTO |
|
MGSF15 |
0.15 |
Separator Acrylic Gel Separator |
21.0 |
99 |
BTO |
|
MGSF17.5 |
0.175 |
Separator Acrylic Gel Separator |
22.0 |
99 |
BTO |
|
MGSF20 |
0.2 |
Separator Acrylic Gel Separator |
22.5 |
99 |
BTO |
|
MGSF25 |
0.25 |
Separator Acrylic Gel Separator |
23.0 |
99 |
BTO |
|
MGSF30 |
0.3 |
Separator Acrylic Gel Separator |
26.0 |
99 |
BTO |
|
MGSF35 |
0.35 |
Separator Acrylic Gel Separator |
30.0 |
99 |
BTO |
|
MGCS50 |
0.5 |
Separator Acrylic Gel Separator |
35.0 （対SUS） |
99 |
BTO |
|
MGCS100 |
1.0 |
Separator Acrylic Gel Separator |
40.0 （対SUS） |
99 |
BTO |
|
High Transparency Double Sided Tape May Clean Gel Series Download
Recommended Lamination Conditions of KGK OCA Download
May Clean Gel "MGSR" Series
Step Followability / Excellent Adhesion to Resin
Product Name |
Thickness |
Structure |
Adhesive Strength |
Tt |
Notes |
Technical Data |
MGSRTD2.5 |
0.025 |
Separator Acrylic Gel Separator |
7.3 |
99 |
BTO |
|
MGSRTD5 |
0.05 |
Separator Acrylic Gel Separator |
11.3 |
99 |
BTO |
|
MGSRTD7.5 |
0.075 |
Separator Acrylic Gel Separator |
15.4 |
99 |
BTO |
|
MGSRTD10 |
0.1 |
Separator Acrylic Gel Separator |
19.9 |
99 |
BTO |
|
MGSRTD12.5 |
0.125 |
Separator Acrylic Gel Separator |
23.1 |
99 |
BTO |
|
MGSRTD17.5 |
0.175 |
Separator Acrylic Gel Separator |
23.6 |
99 |
BTO |
|
MGSRTD20 |
0.2 |
Separator Acrylic Gel Separator |
23.8 |
99 |
BTO |
|
MGSRTD25 |
0.25 |
Separator Acrylic Gel Separator |
23.9 |
99 |
BTO |
|
MGSRTD35 |
0.35 |
Separator Acrylic Gel Separator |
24.4 |
99 |
BTO |
|
MGSRTD50 |
0.5 |
Separator Acrylic Gel Separator |
25.3 |
99 |
BTO |
|
MGSRTD100 |
1.0 |
Separator Acrylic Gel Separator |
28.0 |
99 |
BTO |
|
MGSRTD200 |
2.0 |
Separator Acrylic Gel Separator |
33.5 |
99 |
BTO |
|
May Clean Gel "MGU" Series
Step Followability / UV Cure Type
Feature
Adhesive gel sheet based on extremely high transparency and acrylic resin. An excellent double-sided tape that has excellent step absorption and UV curing after bonding to strengthen adhesion.
Application
For bonding optical members such as LCD, OLED and touch sensor. This product contributes to improving the visibility of the display by filling the gap between the optical members.
Product Name |
Thickness |
Structure |
Adhesive Strength |
Adhesive Strength |
Notes |
Technical Data |
MGU2.5 |
0.025 |
Separator Special Gel Separator |
7.0 |
10.0 |
BTO |
|
MGU7.5 |
0.075 |
Separator Special Gel Separator |
7.0 |
10.0 |
BTO |
|
MGU10 |
0.1 |
Separator Special Gel Separator |
7.0 |
10.0 |
BTO |
|
MGU17.5 |
0.175 |
Separator Special Gel Separator |
8.0 |
11.0 |
BTO |
|
MGU25 |
0.25 |
Separator Special Gel Separator |
9.0 |
12.0 |
BTO |
|
MGU50 |
0.5 |
Separator Special Gel Separator |
11.0 |
16.0 |
BTO |
|
MGU100 |
1.0 |
Separator Special Gel Separator |
14.0 |
20.0 |
BTO |
|
MGU200 |
2.0 |
Separator Special Gel Separator |
21.0 |
29.0 |
BTO |
|
May Clean Gel "MGUC" Series
UV Cut / High Transparency
Feature
Adhesive gel sheet based on extremely high transparency and acrylic resin. Double-sided tape with excellent absorption in the ultraviolet wavelength range (100 to 400 nm) and optical reliability.
Application
For bonding optical members such as LCD, OLED and touch sensor. This product contributes to improving the visibility of the display by filling the gap between the optical members.
Product Name |
Thickness |
Structure |
Adhesive Strength |
Tt |
Notes |
Technical Data |
MGUC2.5T4 |
0.025 |
Separator Special Gel Separator |
2.0 |
99 |
BTO |
|
MGUC5T4 |
0.05 |
Separator Special Gel Separator |
3.0 |
99 |
BTO |
|
MGUC20T4 |
0.2 |
Separator Special Gel Separator |
8.0 |
99 |
BTO |
|
May Clean Gel "MGS_D" Series
Smoke Color / High Adhesion
Feature
This product is extremely high transparency and adhesive gel sheet based on acrylic resin called organic glass.
This product is optically excellent double sided tape such as strong adhesion, shock absorption, reliability and prevention of corrosion of metal film of touch sensor.
This product is optically excellent double sided tape such as strong adhesion, shock absorption, reliability and prevention of corrosion of metal film of touch sensor.
Application
For bonding optical members such as LCD, OLED and touch sensor. By filling the gap between the optical members, this product contributes to improving the visibility by adjusting the light shielding property and color tone of the display.
Product Name |
Thickness |
Structure |
Adhesive Strength |
Tt |
Notes |
Technical Data |
MGS2.5D |
0.025 |
Separator Special Gel Separator |
2.0 |
60 |
BTO |
|
MGS5D |
0.05 |
Separator Special Gel Separator |
4.0 |
60 |
BTO |
|
MGS10D |
0.1 |
Separator Special Gel Separator |
6.0 |
60 |
BTO |
|
MGS17.5D |
0.175 |
Separator Special Gel Separator |
6.0 |
60 |
BTO |
|
MGS20D |
0.2 |
Separator Special Gel Separator |
6.0 |
60 |
BTO |
|
May Clean Gel Silicon Type "MGSi" Series
Reliability / Shock Absorption
Feature
Adhesive gel sheet based on smoke color and acrylic resin.Double-sided tape with excellent light-shielding properties, strong adhesion, shock absorption, and reliability.
Application
For bonding optical members such as LCD, OLED and touch sensor. This product contributes to improving the visibility of the display by filling the gap between the optical members.
Product Name |
Thickness |
Structure |
Adhesive Strength |
Tt |
Notes |
Technical Data |
MGSiH5 |
0.05 |
Separator Silicon Gel Separator |
10.5 |
92 |
BTO |
|
MGSiH10 |
0.1 |
Separator Silicon Gel Separator |
10.8 |
92 |
BTO |
|
MGSiH17.5 |
0.175 |
Separator Silicon Gel Separator |
11.0 |
92 |
BTO |
|
MGSiH25 |
0.25 |
Separator Silicon Gel Separator |
0.25 |
92 |
BTO |
|
MGSiH100 |
1.0 |
Separator Silicon Gel Separator |
0.3 |
92 |
BTO |
|
Silicone Type May Clean Gel Series Download
